Balustrade OP6

The safety fence is perfect for separating pedestrian and vehicle traffic in an urban space.

– dimensions: (L) 2000 x (H) 1100 mm
– pipe diameter Ø48.3 mm
– finish: powder coating, paint+zinc, galvanized, stainless steel
– installing method: concreteable
– weight: 10 kg

OP17 is a single inline handrail / mid & bottom rails for stairs and level applications under one metre (FFL) and typical fire stair applications.
Smart clamps and a steel pipe with a size of Ø 48 mm are used for assembly. If desired, the safety barrier can also be assembled from Ø42 or Ø60mm pipe.
As a standard solution, the railings are hot-dip galvanized.

OP22 is top rail / handrail bikeway barrier with offset top rail and handrail for level and rake.
Smart clamps and a steel pipe with a size of Ø 48 mm are used for assembly. If desired, the safety barrier can also be assembled from Ø42 or Ø60mm pipe.
As a standard solution, the railings are hot-dip galvanized.

OP24 is top rail / handrail & bottom rail bikeway barrier with offset top rail, handrail and bottom rail for level and rake.
Smart clamps and a steel pipe with a size of Ø 48 mm are used for assembly. If desired, the safety barrier can also be assembled from Ø42 or Ø60mm pipe.
As a standard solution, the railings are hot-dip galvanized.

GRAVITY-CLOSING SAFETY GATES
The most efficient and durable way to protect people against accidental falls through guardrail openings.

• Proven design successfully used over 38 years
• Maintenance free
• Service life > 30 years
• TÜV tested, EN ISO 14122-3

DESIGN
• Gate automatically closes due to gravity
• Rises when opened; Returns closed when released
• Design does not depend on springs, cams, bearings, or the operator
• Gate has a horizontal swing, not a vertical drop
• Available in 4 standard sizes: 560, 690, 820, 950 mm

Protective railings made of 70 × 70 mm square post with height H1000 mm
cross bar 60x40 mm with lengths: 800, 1300, 1800 mm
hot-dip galvanized and coated yellow with black-striped
ground-mounted base plate
base plate dimensions: 100 x 150 mm
for protecting work sites, machines and facilitites or gateways
