E-bike lean-on

By using bicycle racks, you offer the opportunity to store bicycles in an organized manner. The closed shape offers support and the ability to tie down the bike to prevent theft. The simple design makes these bike racks functional and durable.

Dimensions: 1050*150*1070mm
Weight: 13 kg

Bicycle racks have:
• Standard base plate for installation
below the ground
• Height from the ground 900 mm
level
• Warranty 5 years

Material according to the series (different material choices in the series):
AROS 1
• Corten steel pipe 60x40x2 mm
or
• Galvanized steel pipe 60x40x2 mm

AROS 2
• Galvanized steel pipe ø 40x2 mm
or
• Stainless steel 316 pipe ø42x2 mm

BORG
• Corten steel 8 mm
or
• Galvanized steel 8 mm

STOR
• Corten steel 10 mm
or
• Galvanized steel 10 mm.

Maintenance:
Regular cleaning and oiling of the wood ensures that the pigment in the wood is preserved longer and the discoloration process is delayed.
• Annual cleaning and dirt removal with clean water.

NB! Do not use a pressure washer.

hoop of steel tube Ø 48 x 2,5 mm
total width 500 mm, the total height of 1400 mm
casting in concrete
hot-dip galvanized

hoop of steel tube Ø 48 x 2,5 mm
total width 500 mm, the total height of 1400 mm
casting in concrete
hot-dip galvanized

Models: 6 spaces
Max. diameter handlebar support: ø 45 mm
Dimensions version with legs: 598 high x 1006 long x 245 mm deep
Structure: galvanised steel
System: automatic grip/release of steering column, eyelets for locking (padlock not included)
Finish: galvanised and painted in our colours
Installation: base plates for version with legs (not supplied)

E-bike ring with charging station. Choice of holder for 1 or 3 wheels.

- IP 67 (IP54) output socket 230 V,
- with lock
- charging box,
- square tube 100x100mm / 60x60mm
- width: 800 mm
- total height: 800 mm,
- sole connection to the ground
- hot-dip galvanized and black coating

Mobile bike rack with advertising label

·for stable fixing of bicycles with rotating holding devices
with drive wheels
tire widths 6x up to 55 mm / 3x up to 45 mm
finish: galvanized, coated RAL 9005

Choice of 2 models:
- without sockets
- 3x socket IP54, 2x with dock for charging electric bikes.
