Ornamental bollard Ø76mm

Ornamental bollard, Ø60mm.

5 different bollards in selection:
1. Stationary, for casting in concrete, with ground anchor, total length: approx. 1300mm. 5kg
2. Stationary, to be fixed by plugs, with base plate 100 x 150mm. 4kg
3. Removable, with triangular locking mechanism, self-engaging lock, with hot-dip galvanized ground socket part-no. 460.40: approx. 400 mm below ground. 7kg
4. Foldable, with triangular locking mechanism, self-engaging lock, to be fixed by plugs, with base plate 100 x 150 mm. 6kg
5. Foldable, with triangular locking mechanism, self-engaging lock, for casting in concrete, with hot-dip galvanized ground socket part-no. 470.60, approx. 400 mm below ground

- approx. 950mm above ground
- hot-dip galvanized and coated colour RAL 7016

Ornamental bollard, Ø76mm

5 different bollards in selection:
1. Stationary, for casting in concrete, with ground anchor, total length: approx. 1300mm. 7,5kg
2. Stationary, to be fixed by plugs, with base plate 100 x 150mm. 6,5kg
3. Removable, with triangular locking mechanism, self-engaging lock, with hot-dip galvanized ground socket part-no. 476.40: approx. 400 mm below ground. 12kg
4. Foldable, with triangular locking mechanism, self-engaging lock, to be fixed by plugs, with base plate 100 x 150 mm. 8kg
5. Foldable, with triangular locking mechanism, self-engaging lock, for casting in concrete, with hot-dip galvanized ground socket part-no. 470.60, approx. 400 mm below ground. 10,5kg

- approx. 950mm above ground
- hot-dip galvanized and coated RAL 7016

Ornamental bollard, Ø76mm.

3 different bollards in selection:
1. Stationary, for casting in concrete, with ground anchor, total length: approx. 1300mm. 6,5kg
2. Stationary, to be fixed by plugs, with base plate 100 x 150mm. 5,5kg
3. Removable, with triangular locking mechanism, self-engaging lock, with hot-dip galvanized ground socket part-no. 476.40: approx. 400 mm below ground. 11,5kg

- approx. 900mm above ground
- flat head
- hot-dip galvanized and coated DB 703

Conical ornamental bollard Ø102/76mm.

3 different bollards in selection:
1. Stationary, for casting in concrete, with ground anchor, total length: approx. 1300mm.
2. Stationary, to be fixed by plugs with base plate Ø180 mm.
3. Removable, with triangular locking mechanism, self-engaging lock, with hot-dip galvanized ground socket part-no. 470.10: approx. 500 mm below ground.


- approx. 900mm above ground
- with ornamental cap
- hot-dip galvanized and coated RAL 7016

DIMENSIONS
height: 110 cm
diameter: 6/9 cm
weigth: 17 kg

MATERIALS
varnished steel and varnished polymer composite

INSTALLATION
The bollard is installed by setting anchoring pipes in the concrete

COLOR CHOICE: dark grey, black

Bollard light
Tubular steel Ø 152mm, total height 1000mm,
hot-dip galvanised, powder-coated
Fixing: for dowelling
Voltage: 230V AC 50Hz, power: 12W,
luminous flux: 1050 lm, colour temperature: 4,000 K, light colour: white
weigth 16kg
