Ornamental bollard Ø76mm

Ornamental bollard, Ø76mm

5 different bollards in selection:
1. Stationary, for casting in concrete, with ground anchor, total length: approx. 1300mm. 7,5kg
2. Stationary, to be fixed by plugs, with base plate 100 x 150mm. 6,5kg
3. Removable, with triangular locking mechanism, self-engaging lock, with hot-dip galvanized ground socket part-no. 476.40: approx. 400 mm below ground. 12kg
4. Foldable, with triangular locking mechanism, self-engaging lock, to be fixed by plugs, with base plate 100 x 150 mm. 8kg
5. Foldable, with triangular locking mechanism, self-engaging lock, for casting in concrete, with hot-dip galvanized ground socket part-no. 470.60, approx. 400 mm below ground. 10,5kg

- approx. 950mm above ground
- hot-dip galvanized and coated RAL 7016

Ornamental bollard, Ø82mm

8 different bollards in selection:
1. Stationary, for casting in concrete, with ground anchor, total length: approx. 1300mm. 9,5kg
2. Stationary, to be fixed by plugs, with base plate 100 x 150mm. 8,5kg
3. Removable, with triangular locking mechanism, self-engaging lock, with hot-dip galvanized ground socket part-no. 470.10: approx. 500 mm below ground. 13kg
4. Removable, with profile cylinder lock (three keys incl.) self-engaging lock, with hot-dip galvanized ground socket part-no. 470.10: approx. 500 mm below ground. 13kg
5. Foldable, with triangular locking mechanism, self-engaging lock, to be fixed by plugs, with base plate 100 x 150 mm. 9kg
6. Foldable, with cylinder lock (three keys incl.) self-engaging lock, with base plate 100 x 150mm. 10kg
7. Foldable, with triangular locking mechanism, self-engaging lock, for casting in concrete, with hot-dip galvanized ground socket part-no. 470.60, approx. 400 mm below ground. 11kg
8. Foldable, with cylinder lock (three keys incl.) self-engaging lock for casting in concrete, with hot-dip galvanized ground socket part-no. 470.60, approx. 400 mm below ground. 12,5kg

- approx. 900mm above ground
- hot-dip galvanized and coated RAL 9005 (jet black)

Ornamental bollard, Ø89mm

2 different bollards in selection:
1. Stationary, for casting in concrete, with ground anchor, total length: approx. 1300mm.
2. Removable, with triangular locking mechanism, self-engaging lock, with hot-dip galvanized ground socket part-no. 470.10: approx. 500 mm below ground.

- approx. 950mm above ground
- with globe head
- hot-dip galvanized and coated RAL 7016

Conical ornamental bollard Ø168/96mm.

3 different bollards in selection:
1. Stationary, for casting in concrete, with ground anchor, total length: approx. 1050mm.
2. Stationary, to be fixed by plugs with base plate 220 x 220 mm.
3. Removable, with triangular locking mechanism, self-engaging lock, with hot-dip galvanized ground socket part-no. 470.10: approx. 500 mm below ground.


- approx. 750mm above ground
- with ornamental cap
- hot-dip galvanized and coated in antique brown RAL 8019

DIMENSIONS
height: 110 cm
diameter: 7,6 cm
weigth: 13 kg

MATERIALS
varnished steel and varnished polymer composite

INSTALLATION
The bollard is installed by setting anchoring pipes in the concrete

COLOR CHOICE: dark grey, black

DIMENSIONS
height: 80 cm
diameter: 28 cm
weigth: 70 kg

MATERIALS
painted concrete

INSTALLATION
The bollard is installed by setting anchoring pipes in the concrete

COLOR CHOICE: grey, light graphite, graphite
