Type 20, Three Way Through Ø60,3

Swivel Base Plate (Unisize). For fixing structures to wall or floor, usually used with Type 42.

Railing Base Flange. Strong baseplate to support vertical post. Vertical wide rib with two setscrews increases the strength of the clamp. The fixing holes in the base flange should be in line with the applied load.

Three Way Top Corner. Corner joint (90°) clamp used for top rail corners and any other rectangular system.

Short Tee. Provides a perpendicular connection between two tubes. Top fitting for straight and level railing uprights. This fitting cannot be used to join a horizontal tube within the fitting.

Groundsocket. A ground socket fitting inside the concrete for fixing upright tube. Post is retained with a locking setscrew, allowing easy insertion and removal (if necessary).

Straight Coupling. Joint clamp for tubes of the same diameter. Do not use for heavy vertical loads. Alternative clamp is Type 9 used as an internal spigot.
