Type 57, Collar Plate Double Side 90° Ø48,3mm

Base flange for sloping sites, adjustable from 30° to 45°. As the fixing holes in the base cannot be fixed in line with the applied load, it is only intended for light loads or structures which are sufficiently supported by virtue of their design. Where a greater load is required, type 132 is normally used, with the upright tube bent to the required angle.

Wall Flange. This clamp is used on structures where positional fixing is required. Do not use as a base flange to support guard railings or similar systems.

Railing Base Flange. Strong baseplate to support vertical post. Vertical wide rib with two setscrews increases the strength of the clamp. The fixing holes in the base flange should be in line with the applied load.

Short Slope Tee Variable angle 0° - 11°. Top fitting for up to 11° uprights. This fitting can not be used to join horizontal tube within the fitting.

Male Single Lug. Used with Type 42 for swivel fittings, also used for fixing panels and boards.

Collar Plate Single Side. Front adjustment scew. Fitting for panel fixing.
