Type 61, Hook Ø48,3

Swivel Base Plate (Unisize). For fixing structures to wall or floor, usually used with Type 42.

Base flange for sloping sites, adjustable from 30° to 45°. As the fixing holes in the base cannot be fixed in line with the applied load, it is only intended for light loads or structures which are sufficiently supported by virtue of their design. Where a greater load is required, type 132 is normally used, with the upright tube bent to the required angle.

To attach the handrail to an upright at any angle.

Wall Flange. This clamp is used on structures where positional fixing is required. Do not use as a base flange to support guard railings or similar systems.

Angle Cross 0°- 45°. Connection clamp between the middle rail and the railing posts of sloping railings up to 45°.

Short Tee. Provides a perpendicular connection between two tubes. Top fitting for straight and level railing uprights. This fitting cannot be used to join a horizontal tube within the fitting.
